OBD2 Code Reader Scanner with Reset, Mode 6/8, I/M Readiness

Name: OBD2 Code Reader Scanner with Reset, Mode 6/8, I/M Readiness
Brand: Perlikal
SKU: RESMO001
Price: 14.99 USD
Availability: InStock

OBD2 Code Reader Scanner with Reset, Mode 6/8, I/M Readiness

$14.99

~~$19.99~~ $14.99

Sale Sold out

Shipping calculated at checkout.

In stock, ready to ship

Fast Access to Dashboard Data

This handheld OBD2 scanner uses a 16-pin OBD2 connector and an onboard code library with 35,901 DTC definitions for offline reference. It has a 2.8 in screen for viewing stored codes, pending codes, and ECU data parameters without an external display. Mode 6 access shows on-board monitor test values when the vehicle ECU reports them.

OBD2 Code Reader Scanner with Reset, Mode 6/8, I/M Readiness

What the Port Reports

Connect the tool to the vehicle OBD2 diagnostic port with the ignition in the required key position per the vehicle service procedure. It reads and clears emission-related diagnostic trouble codes, displays freeze-frame records, and shows live data from supported PIDs. I/M readiness status is shown for supported monitors, and Mode 8 component test commands are available on vehicles that accept them. It can also request VIN and display vehicle system voltage when supported.

OBD2 Code Reader Scanner with Reset, Mode 6/8, I/M Readiness

Plug In, Navigate, Stow

Insert the 16-pin connector into the OBD2 port, then use the menu keys to select code readout, erase, readiness, live data, or monitor functions. For printed records, connect the scanner to a computer using the included USB Type-C cable. Store the unit and cable in the included canvas bag to keep the connector and screen covered during transport.

Product Benefits:

Code Library: Stores 35,901 DTC definitions on the unit for offline lookup.
Built-In Display: 2.8 in screen shows stored codes, pending codes, and supported ECU data without an external display.
DTC and Freeze Frame: Reads and clears emission-related DTCs and displays freeze-frame records when reported by the ECU.
Monitor Functions: Displays I/M readiness for supported monitors and provides Mode 6 on-board monitor test values when available.
Connectivity and Storage: Uses a 16-pin OBD2 plug for vehicle connection; includes a USB Type-C cable for PC transfer in a supported Windows environment and a canvas storage bag.

Specification:

Product Type: Handheld OBD2 diagnostic scanner
Dimensions: 7.3 × 4.1 × 1.6 in
Display: 2.8 in built-in screen
Diagnostic Functions: Reads/clears DTCs, freeze-frame, live data, I/M readiness, Mode 6 and Mode 8 (vehicle-dependent)
DTC Library: 35,901 onboard definitions for offline reference
Vehicle Connection: 16-pin OBD2 diagnostic connector
PC Connection: USB Type-C port
PC Compatibility: Windows operating systems (including legacy versions)
Power Source: Battery powered (battery type not specified)
Use Location: Vehicle interior; OBD2 port access area

30-Day Return Policy

Return window: You can return items within 30 days of delivery
Restocking fees: None
Exchanges: Yes, we accept them
Refund timing: Processed within 7 days after approval
Return shipping: Paid by the customer
Note: This policy works alongside our Terms of Service

For more information, please check our Return and Refund Policy.

Free Shipping

Cut-Off Time: 4:00 PM EDT for same-day processing
Order Prep: 0–1 business days (Monday – Friday)
Delivery Speed: 5–9 business days (Monday – Friday)
Shipping Cost: Free delivery applies to all orders shipped within the United States

For more information, please check our Shipping Policy.

View full details

the I/M readiness screen breaks down each monitor individually, so you can see which ones are complete and which ones are still running. makes it really easy to know if the car is actually ready for emissions or if you need to drive it a bit more first.

does exactly what I need it to do.

Really happy with this. Clears codes fast and the screen is easy to read in a parking lot.

the reset function works cleanly. clear the code, it confirms it, and the check engine light goes off. then you can monitor the readiness status as the car runs its drive cycle. really helpful for knowing when everything has reset properly after a repair.

what I like is that it reads both generic OBD2 codes and the manufacturer-specific ones. pulled a pending code on my truck that a cheaper reader completely missed. the freeze frame data shows up too which helps figure out what conditions triggered the fault.

I keep this in my glovebox and it has come in handy more than once. Simple to use and the readiness monitors give me confidence before heading to inspection.

told my coworker to grab one of these because she was nervous about buying a scanner online after getting burned by one that only worked on newer cars. she has a 2005 Honda and it read her codes no problem. she was happy with it right away.

the Mode 6 data on this thing is genuinely useful. it shows the actual test values and the limits side by side so you can see how close a sensor is to failing, not just whether it passed or failed. I didn't expect that level of detail at this price.

Every time I've used it, it connects within a few seconds and pulls up the info I need. No fuss, no fumbling around. My neighbor borrowed it last week and ended up ordering his own copy.

I was worried it would only clear codes without actually showing whether the monitors were ready, but the I/M readiness display is right there and easy to read. saved me a wasted trip to the inspection lane.
